JBB Type Mechanical Diaphragm Metering Pump Manufacturers ISO Approved

Name: JBB Type Mechanical Diaphragm Metering Pump Manufacturers ISO Approved
Brand: DENOR
Price: 1000 USD

Wholesale JBB Type Mechanical Diaphragm Metering Pump Manufacturers ISO Approved from china suppliers

Brand Name : DENOR

Model Number : DENOR-JLB

Certification : ISO/CE/TUV

Place of Origin : China

MOQ : 1

Price : 1000—2000

Payment Terms : T/T

Supply Ability : 30sets/month

Delivery Time : 5-8 work days

Packaging Details : Wooden case packing

Temperature Range : 0-80℃

Name : Mechanical Diaphragm Metering Pump

Accuracy : ±0.5%

Frequency : 50/60Hz

Voltage : 110V/220V

Material : Stainless Steel/Plastic

Pressure : 0-10MPa

Power Supply : AC/DC

Application : Water Treatment/Chemical Industry

Flow Rate : 0.1-2000L/h

Control Mode : Manual/Automatic

Viscosity Range : 1-8000mPa.s

Inlet/Outlet Size : 1/4

Protection Level : IP55/IP65

Contact Now

JBB type mechanical diaphragm metering pump

Pump head	Diaphragm	Ball valve	Seat O-ring	Pharmaceuticals
PVC	PTFE/EPDM	Ceramic	PTFE/EPM	Sodium hypochlorite, aluminum sulfate, ferrous chloride, PAC, sulfuric acid, hydrochloric acid, phosphoric acid, urea, calcium chloride, aluminum chloride, defoaming agent, etc.
304/316		304/316	EPDM	Coagulant, ammonia water, hydrazine, caustic soda
PTFE		304/316	EPDM	Coagulant, ammonia water, hydrazine, caustic soda

JBB series mechanical diaphragm metering pumps are designed for precise metering and quantitative addition of a variety of chemicals. They are widely used in various industrial applications, such as sewage treatment, petrochemicals, food and beverage, pharmaceuticals, papermaking, laboratories, and electronics.

Product Advantages

● A variety of pump head materials are available: PVC, PTFE, stainless steel 304, stainless steel 316.

● The flow rate can be adjusted freely during operation. No leakage in structure. Suitable for various acid and alkali resistant liquids.

● Using high-quality PTFE and rubber composite diaphragm, it is highly corrosion-resistant and greatly improves the service life of the diaphragm.

● Applicable to various acid and alkali resistant liquid medicines. Can be installed on the medicine tank. Easy to install, repair and maintain. High operating safety performance.

Performance parameters

model	Flow rate (L/H)	Pressure(Mpa)	Stroke(mm)	Pump speed (min - 1 )	Pump head diameter (mm)	Diaphragm diameter(mm)	Motor power(W)	Inlet and outlet diameter (mm)
JBB 5/1.0	5	1	3	75	90	60	60	φ9 hose with filter bottom valve and injection valve
JBB 10/1.0	10	1	3	75	90	60	60	φ9 hose with filter bottom valve and injection valve
JBB 20/1.0	20	1	3	100	90	60	60	φ9 hose with filter bottom valve and injection valve
JBB 30/1.0	30	0.8	3	100	90	60	60	φ9 hose with filter bottom valve and injection valve
JBB 40/0.0	40	0.8	4	120	90	60	60	φ9 hose with filter bottom valve and injection valve
JBB 60/0.6	60	0.6	4	100	110	84	60	DN15
JBB 80/0.5	80	0.5	5	100	110	84	60	DN15
JBB 100/0.5	100	0.4	5	120	110	84	60	DN15
JBB 120/0.4	120	0.4	5	150	110	84	60	DN15

Available voltage: 380V, 220V, DC
